P1.86 Flexible LED Video Screen
Flexible Design
Full Customization
Soft Film Flexibility
Seamless Splicing with adjustable angle
Product Introduction
P1.86 Flexible LED Video Screen is built with 320*160mm flexible LED modules. The Flexible module is available in ultra-fine pixel pitches (P1.25, P1.5, P1.8, P2, P2.5) for high-resolution viewing and can achieve seamless splicing with an adjustable gap. Achieve a smooth surface, can splice a variety of sizes or shapes.
Soft film flexibility, our flexible LED display screen is suitable for cylindrical, spherical, S-shaped, and other curved screens.
Product Specification
|
Items |
R1.25 |
R1.53 |
R1.86 |
R2.0 |
R2.5 |
|
Module Size (mm) |
320*160 |
||||
|
Resolution (dots) |
256*128 |
208*104 |
172*86 |
160*80 |
128*64 |
|
Cabinet Sizr (mm) |
640*480 |
||||
|
Scan (s) |
1/64 |
1/52 |
1/43 |
1/40 |
1/32 |
|
Visible Angle |
H / V ≤140° |
||||
|
Flatness |
≥98% |
||||
|
Gray Scale (bit) |
≥13 |
≥12 |
|||
|
Color Temperature |
2000K～9500 K |
||||
|
Contrast |
4000:1 |
||||
|
IP Rate |
IP30 |
||||
|
Refresh Rate (hz) |
≥3840 |
||||
|
Brightness (cd/ m²) |
500-800 |
||||
|
Peak Power |
≤25 W/PCS |
≤15 W/PCS |
≤13.5 W/PCS |
≤12 W/PCS |
≤12 W/PCS |
|
Average power |
10-15 W/PCS |
8-10 W/PCS |
5-10 W/PCS |
5-10W/PCS |
5-10 W/PCS |
Product Details
(1)Our flexible LED modules are designed with soft film technology that allows them to bend back and forth into a specific arc. This makes them suitable for creative applications, such as curved, cylindrical, spherical, or curved surfaces.
(2)The soft LED modules feature a silicon-based construction with an integrated silicone frame and an embedded magnet on the back. This design helps ensure stability during installation and minimizes gap issues between the tiles.
(3)Supports both front and rear maintenance. The installation of theP1.86 Flexible LED Video Screen panel adopts strong magnetic adsorption installation, simply attach the module to a steel structure or magnetic surface using the built-in magnet for installation, making installation and maintenance straightforward..
(4)Thanks to the modular, cable-free design, setup is quick and clean – just prepare the surface, align the modules and connect.
Our Service
(1)Warranty Service: Our LED Products are covered under a 2-5-year warranty as per the contract.
(2)24/7 Online Support: Round-the-clock phone support is available during the warranty period.
(3)Technical Support: Our experienced technicians offer prompt and detailed LED Display solutions to address your technical issues.
(4)Upgrades & Updates: Regular software updates and feature enhancements tailored to customer needs.
(5)Customer Feedback: We actively collect feedback and improve our services accordingly.
(6)On-site Maintenance: Regional technicians are available for on-site support and technical training if needed.
FAQ
Q: How to proceed an order for Flexible LED display?
A: First, let us know your requirements or applications. Then, we design the whole led display solution for you and quote according to your requirements or applications. Third, customer confirms the document and places deposit for order. Last, we arrange the products.
Q: Is it OK to print my LOGO on the LED display product?
A: Yes, and please inform us formally before our production and confirm the design firstly.
Q: What certifications do your flexible LED displays have?
A: All JIUWLDS LED displays are CE, RoHS, and FCC certified, ensuring compliance with international safety and performance standards. This makes them suitable for projects in Europe, North America, Asia, and beyond.
Q: Are flexible LED displays energy efficient?
A: Yes. Our LED modules are designed with low power consumption technology while maintaining high brightness and refresh rate. This helps reduce long-term operating costs, especially for 24/7 usage in commercial spaces.
